Applications that benefit from GPU acceleration include video editing, 3D animation, CAD, computer modeling, cryptography, complex mathematical computations, and any other applications involving calculations that GPU architecture is more efficient at processing than the CPU. In addition to driving displays, the card features broad API support including CUDA, OpenCL, DirectX 11.2, Shader Model 5.0, and OpenGL 4.3, allowing it to provide GPU acceleration for a growing number of GPU-aware applications. For video walls and other larger multi-display setups, up to four K6000s can be installed in one workstation, allowing a single computer to manage a total of 16 displays.
#Quadro k6000 professional
In addition, it supports professional 3D displays and features a stereo connector that will provide synchronization for certain types of active 3D glasses.įor extended desktops, multi-view applications, immersive gaming, and other multi-monitor arrangements, up to four displays can be connected concurrently to one card. Using the DisplayPort outputs the card can drive displays with up to 4K (4096 x 2160) resolution at up to 60 Hz and can drive digital displays through dual-link DVI at up to 2560 x 1600 resolution at up to 60 Hz. They feature feature a dual-link DVI-I (digital and analog) port, a dual-link DVI-D (digital only) port, and two DisplayPort ports with DP 1.2 support. The K6000 cards can be connected to a variety of display types, including computer monitors, HDTVs, broadcast video monitors, projectors, as well as 4K and 3D displays. In addition, 2880 CUDA cores (stream processors) allow the card to perform hundreds of computations simultaneously when interacting with APIs that support parallel processing. When connecting multiple displays to create a video wall, the sync card synchronizes the outputs to make sure the displays refresh simultaneously to prevent tearing and flickering.Įach Quadro K6000 features 12GB of DDR5 RAM and a 384-bit memory interface, which work together to move data to and from the GPU as efficiently, and with as little latency, as possible. Included in the kit are two Quadro K6000 GPUs and an NVIDIA Sync Card. If you’re at the Siggraph conference in Anaheim this week, you’ll be able to see the K6000 being demoed at Nvidia’s booth.The PNY Dual NVIDIA Quadro K6000 Ultra-High Res Video Wall Kit is a turnkey solution for driving a video wall with up to 8 displays. Nvidia hasn’t revealed pricing details yet, but you can bet the card won’t be cheap. The Quadro K6000 is scheduled to start shipping in September or October. The Tesla K20X, which has half the memory and 24% less SP throughput than the new Quadro, is rated for 235W. That may be 103W more than the K5000’s thermal envelope, but it’s 25W less than the rating attached to the GeForce GTX Titan. Nvidia says the extra memory is needed to accommodate the larger data sets being used by artists, designers, and folks in the oil-and-gas industry.ĭespite its impressive horsepower, the Quadro K6000 has a modest 225W TDP.
With 12GB of memory onboard, it also has a lot more RAM overall. Thanks to a wider memory interface and speedy GDDR5 RAM, the Quadro K6000 offers substantially more memory bandwidth than K5000.
In the Tesla K20 series, the GK110’s DP throughput is about one third its SP rate. The Quadro K5000’s GK104 GPU is limited to crunching double-precision math at just 1/24th the rate of single-precision work. Nvidia doesn’t quote double-precision figures, but expect the new hotness to be a substantial improvement on that front. The Quadro K6000 promises 2.4 times the single-precision throughput of the K5000. Here’s how the K6000 stacks up against its predecessor. With all of its GPU resources intact, the Quadro K60 shader ALUs-nearly double the number present in Nvidia’s previous Quadro flagship. The GeForce and Tesla cards derived from the same silicon have at least one SMX unit disabled, leaving them with no more than 2688 ALUs. It’s also the first implementation to use all 15 of the chip’s SMX units. Designed and built specifically for professional workstations, NVIDIA Quadro GPUs power more than 200 professional applications across a broad range of industries including manufacturing, media and entertainment, sciences, and energy. Now, the chip has made its way into a workstation-focused product: the Quadro K6000.Īlthough Nvidia has a handful of Kepler-based Quadros, this is the first to tap the GK110 GPU. This makes the NVIDIA Quadro K6000 the superior choice to bring your largest and most complex projects to life. This seven-billion-transistor monster underpins the GeForce GTX Titan graphics card and the compute-oriented Tesla K20 family. Nvidia’s GK110 GPU is the big daddy of the Kepler generation.
